A lot of dust is generated during the compression process. This dust if not controlled, settles in the upper punches, turret and other parts in the compression zone. Excess dust in the compression zone can lead to black particles, upper punch jamming and various other problems. It is therefore advisable to have a dust collector unit attached to the tablet press to collect the dust generated.
- All Stainless-Steel construction with S316 contact parts
- Antistatic 5 micron filter
- Hepa Filter at exhaust
- Dust collection area is isolated from suction pump and motor
- Collection drum is easily detachable and can be taken to washing area
- Provision to connect De-dusters and Vacuum-cleaning hose
| MODEL | 75CFM | 100CFM | 200CFM | 300CFM |
| SUCTION CAPACITY | 85CFM (150 m3/hr) |
120CFM (240 m3/hr) |
235CFM (400m3/hr) |
330CFM (560 m3/hr |
| NO. OF BAGS | 1 | 1 | 1 | 1 |
| FILTRATION AREA | 2865 sq.cm. | 5254 sq.cm. | 5254 sq.cm. | 5254 sq.cm. |
| DUST COLLECTION AREA | 34.37 ltr | 71.5 ltr | 71.5 ltr | 71.5 ltr |
| COLLECTION DRUM | SS 316 | SS 316 | SS 316 | SS 316 |
| CONSTRUCTION | SS 304 | SS 304 | SS 304 | SS 304 |
| INLET | 2 No – 38mm Dia | 4 No – 38mm Dia | 4 No – 38mm Dia | 4 No – 38mm Dia |
| MOTOR RATING | 1HP | 2HP | 3HP | 5HP |
| DIMENSION LxWxH mm | 455 x 625 x 1405 | 490 x 900 x 1340 | 490 x 900 x 1340 | 565 x 835 x 1385 |
