SALIENT FEATURES
- Compact design with small footprint
- S. construction to meet GMP norms
- In-built orientation of charging and discharging
- Discharge chute can be rotated to suit Tablet Press outlet
- Quick dismantling and assembling (within 1 min.)
- S. 316 contact parts
- Low maintenance
- PU wheels with S.S. Body
- Vacuum connection to increase de-dusting efficiency
TECHNICAL DETAILS
| TYPE | AED S 4-Dish |
| Inlet Height | 775 to 975mm |
| Outlet Height | 775 to 975mm |
| Output (6mm Tablet) | 325000 |
| Tablet Diameter – Minimum | 5mm |
| Maximum | 40mm |
| Dedusting Length (approx) | 2.25m |
| Speed | Adjustable |
| Inlet Chute Size | 130 x 100mm |
| Outlet Chute Diameter | 50mm |
| Motor Specifications | 0.25HP/3PH/50Hz x 2 nos |
| Power Supply | 22OV/1PH |
| Machine Size (L x B x H cm) | 45 x 60 x 95 |
| Net Weight (kgs) | 75 |
